6230B Time-of-Flight LC/MS

Features

Reduce false positives with better than 1 ppm mass accuracy
Ensure excellent data quality even for fast UHPLC peaks in high-throughput workflows with data acquisition rates up to 44 spectra/second
Identify compounds based on accurate mass, isotopic abundance, and chemical composition using Find by Formula in MassHunter software
Analyze monoclonal antibodies (mAb) with high mass accuracy and resolving power for glycoforms and truncation
Characterize large biologic compounds with a broad mass range of up to 20,000 m/z
Separate target compounds from interferences with high-resolution data
Find impurities at extremely low concentrations, using Agilent Jet Stream technology with low picogram on-column sensitivity
Identify trace-level target compounds in the presence of more abundant matrix compounds with up to five orders of in-spectrum dynamic range
Reduce administrative tasks and risks while eliminating the need for LC/MS expertise with intuitive MassHunter Walkup software
Perform untargeted screening with optional fragmentation data using in-source dissociation
Reduce administrative tasks and risks while eliminating the need for LC/MS expertise with intuitive MassHunter WalkUp software
Go beyond UHPLC separation with support for capillary electrophoresis, SFC, 2D-LC, and even GC-APCI chromatographic interfaces.

Specifications


In-spectra Dynamic Range	5 Orders
Ion Source	ESI AJS APCI MultiMode (ESI+APCI) NanoESI CE-ESI
MS Acquisition Rate	30 spectra/second
MS Mass Accuracy (positive)	<1 ppm RMS
Polarity Switching Duty Cycle	< 1 sec
Software Platform	MassHunter
Supported Software Add-Ons	MassHunter WalkUp Mass Profiler Professional MassHunter VistaFlux MassHunter BioConfirm
TOF Mass Range	m/z 25-20,000
TOF Mass Resolution (FWHM)	> 22,000 at m/z 1522 independent of acquisition rate
Temperature Mass Stability	<2 ppm / 2 °C

Return to top

Technology

Additional technology and software capabilities for LC/Q-TOF

Agilent partners with innovators who provide technologies and software that expand the core capabilities of the LC/Q-TOF portfolio. Learn more about additional capabilities and visit the compatibility matrix to see which ones are offered for your LC/Q-TOF.

Learn More

Basics of LC/MS - a Primer

What is LC-MS? How does it work? Learn more about the typical parts of an LC/MS system, its basic principles of operation, types of LC/MS instruments, and LC/MS applications.

Learn More

Applications

Intact Protein Characterization

LC/MS is widely used by the biopharmaceutical industry for therapeutic protein characterization. The accurate mass provided by time-of-flight (TOF) LC/MS allows for confirmation of the synthetic protein, its impurities, and post-translational modifications (PTM). It can also be used for calculation of drug-to-antibody ratios (DAR) for antibody drug conjugates (ADC), relative quantitation, glycoform, and subunit analyses. Coupled to the Infinity III Bio LC, this is a premier system for sensitive, high-resolution analysis of intact proteins.

Oligonucleotide Quantification and Impurity Analysis

Oligonucleotides have a wide range of applications in genetic testing, research, and forensics. Synthesis of therapeutic oligonucleotides often results in a complex mixture of oligonucleotides and their impurities. Liquid chromatography with high-resolution mass spectrometry allows for profiling of the mixture, relative quantification of the products, and identification by accurate mass. The 6230 LC/TOF is ideal for oligonucleotide analysis, including quantification of synthetic oligos, and impurity analysis as low as 0.5% of the main compound.

Released Glycan Analysis

Critical Quality Attributes (CQA), such as glycosylation, have a significant impact on the efficacy and stability of therapeutic proteins. Glycosylation has historically been analyzed by fluorescence labeling, which does not have sufficient specificity for more complex sample types. The 6230 LC/TOF offers the accurate mass and high resolution required for comprehensive characterization of these glycoforms. This technology can easily be deployed for glycan profiling in the development, manufacturing, and monitoring of biotherapeutics.
