ZORBAX StableBond
ZORBAX StableBond
ZORBAX SB-Aq is an HPLC alkyl reversed-phase bonded phase designed to retain hydrophilic and other compounds when using highly aqueous mobile phases, including 100% water. The SB-Aq surface chemistry is designed to allow the alkyl phase to remain fully accessible in highly aqueous mobile phases, preventing "phase collapse.” Because of this, separations on SB-Aq are reproducible from run to run over long column lifetimes. By contrast, many conventional C18 columns—and even some columns with claimed aqueous compatibility—may exhibit phase collapse, and thus show reduced retention or selectivity changes over time, leading to irreproducible results.
StableBond columns are available in 1.8, 3.5, 5 and 7 μm particle sizes for high speed, high resolution, analytical and prep scale separations.
Find the Agilent LC column you need using the LC Columns Navigator
- Small Molecule Separations
제품 정보
- Longest column lifetime and best reproducibility for low pH separations—down to pH 1
- Patented stable column chemistry allows use at high temperature and low pH without degradation
- Six different bonded phases provide broad selectivity – SB-C18, SB-C8, SB-CN, SB-Phenyl, SB-C3, and SB-Aq
- Different selectivity compared to conventional end-capped chemistries
- High purity (Type B) silica for good peak shape
- SB-Aq offers reproducible retention of polar analytes in aqueous mobile phases
- To compare technical information and specifications for different phases, see our phase specifications chart.
| Bonded Phase | Pore Size | Surface Area | Temp Limits* | pH Range* | Endcapped | Carbon Load | USP Designation |
| ZORBAX SB-C18 | 80Å | 180 m2/g | 90 ºC | 0.8-8.0 | No | 10% | L1 |
| ZORBAX SB-C8 | 80Å | 180 m2/g | 80 ºC | 1.0-8.0 | No | 5.50% | L7 |
| ZORBAX SB-C3 | 80Å | 180 m2/g | 80 ºC | 1.0-8.0 | No | 4% | L56 |
| ZORBAX SB-Phenyl | 80Å | 180 m2/g | 80 ºC | 1.0-8.0 | No | 5.50% | L11 |
| ZORBAX SB-CN | 80Å | 180 m2/g | 80 ºC | 1.0-8.0 | No | 4% | L10 |
| ZORBAX SB-Aq | 80Å | 180 m2/g | 80 ºC | 1.0-8.0 | No | proprietary | L96 |
*StableBond columns are designed for optimal use at low pH. At pH 6-8, highest column stability for all silica-based columns is obtained by operating at temperatures <40 ºC and using lower buffer concentrations in the range of 0.01-0.02 M. At mid-range pH, Eclipse Plus, Eclipse XDB and Bonus-RP are recommended.
