TwisTorr Medium-TMP Rack Controller
The TwisTorr Medium TMP rack controller is a remote unit designed to operate the TwisTorr 404 FS, 704 FS, and 804 FS turbomolecular pumps. This 'half-rack' unit can be rack mounted or standalone. The controller optimizes pump parameters based on application conditions and drives vent valves and air cooling fans.
Capable of running on worldwide voltage, the TwisTorr Medium TMP rack controller can be mounted up to 100 m away from the pump. The controller also offers data monitoring via its display in addition to analog and serial interfaces.
Capable of running on worldwide voltage, the TwisTorr Medium TMP rack controller can be mounted up to 100 m away from the pump. The controller also offers data monitoring via its display in addition to analog and serial interfaces.
Product Details
Features
- Ready for use with the Vacuum Link app to give full pump control through your mobile phone
- Pump cable lengths up to 100 m long for remote controller mounting
- RS232/RS485 communication protocols (and optional Profibus interface) for easy data management
- Analog I/O provides accurate control of the pump
- Remote control with A-plus software enables pump operation, control, and recording of system parameters
- Rack-mounted design for easy integration
- Vent valve and cooling fan driving to give full vacuum system control
- Universal voltage (100–240 V) enables worldwide operation
- Shipped without a power cord, to be ordered separately
